TSF100 turbine flow meters are available in a wide variety of flow and pressure ranges, and are highly customizable to meet the customers' specific needs: parts material, process connection, electrical connection, signal output and housing.
Subsea Turbine Flow Meter
TSF100 Sereis
Introduction
With over 20 years proven experience, our turbine flow meters are engineered for durability and precision in the most demanding environments. Trusted by industry leaders, TSF100 are ideal for offshore operations such as ROVs, BOPs, chemical injections and other critical offshore drilling processes. Built to perform under pressure, they deliver reliable flow measurement where it matters the most.
Features
Robust design for harsh subsea environment
Dual-rotor, dual-output available
Highly customized product
SS316, 316L, Duplex and more material
Multiple process connection / electrical connection
Highly accurate measurement of flow
Well-proven quality
Applications
ROV Skids
ROV Workover Control Systems (RWOCS)
Blowout Preventer (BOP)
Offshore Chemical & Methanol Injection
Subsea Control Systems
Valve actuation
......
Specifications
Max. operating depth:
Max. working Pressure:
Accuracy:
Repeatability:
Linearity:
Outputs:
Bearing Styles:
Pickup up temperature:
Process connections:
Electrical connection:
Wiring protection:
20,000 feet (6000 m)
Internal: up to 15,000 psi (1,035 bar)
External 7,800 psi (600 bar)
Subject to process connection
0.5% of reading
0.1% of reading
Better than 0.5% of reading
Pulse; Dual-pulse; Analog (4…20mA); Dual-analog
Stainless ball bearing / Ceramic hybrid ball bearings
-30°C to 110°C
BSP, NPT, Auto Clave; Din, ASME, SAE flange
Subconn 3-pin connector (could be other connectors customer preferred.
Short-circuit; Reverse polarity
Customization
Our subsea flow meters are highly customizable to match your specific needs:
Parts material
Process connection
Electrical connection
Signal output
Housing.
